• One、 Feature


◆ 64-segment curve programming

◆ Automatic / manual bumpless switching

◆ Concise programming, can jump, loop

◆ RS485 communication, analog transmission function

• Two、Technical parameters


1. Working power: AC / DC85 ～ 260V (other power can be customized)

2. Input signal: T, R, J, WRe3-25, B, S, K, E

Pt100, Cu50, 0 ～ 375Ω, 0 ～ 75mV

0 ～ 30mV, 0 ～ 5V, 1 ～ 5V, 0 ～ 10V, 0 ～ 10mA

0 ～ 20mA, 4 ～ 20mA

3. Accuracy: 0.2% FS ± 1 word

4. Sampling rate: 5 times / second

5. Feed output: DC24V / 25mA

6. Transmission output: 4 ～ 20mA, 0 ～ 20mA

7. Transmission load capacity: not less than 500Ω

8. Communication output: RS485 (MODBUS_RTU protocol)

9. SSR level: DC12V / 25mA

10. Operating environment: 0 ～ 50 ℃; ≤ 85% RH
